Bowes Type Non-Locking Threaded Coupling

Bowes Type Non-Locking Threaded Coupling

from 12.96

Bowes type non-locking couplings are designed to mate with Bowes type safety lock plugs. safety lock plugs feature a retractable sleeve and twist connection. The safety lock retaining ring threads up to the sleeve to prevent accidental disconnection. Interchanges with Bowes 75, National B Series and MacDonald Couplings.

  • Select male or female thread, steel or brass material

  • Non-locking coupling mates to Bowes type male nipple

  • Size listed is the thread size, all coupler sizes interchange

  • Thread is NPT, BSPT is available (inquire)

  • Stainless Steel is available in 3/4" size (inquire)

Size:
Material:
Thread Type:
Quantity:
I'll Take It

500 PSI* @ 70 Degree Operating Temperature *STEEL & STAINLESS STEEL ONLY / 300 PSI BRASS*

-40 to + 250 Deg F Operating Range (working pressure decreases as temperature increases)

Conforms to Mil-C-3486 and A-A-50431A

Steel couplings are plated with ROHS compliant trivalent chrome

Brass Coupling is not lead free (do not use for drinking water or food applications)

WARNING: Cancer and reproductive harm: www.P65Warnings.ca.gov

To achieve 500 PSI operating rating, all components and hoses must be assembled to meet or exceed this rating

Never use Bowes type quick couplings for steam service.
